Brand: ERA SIB
Price Ex Vat: £46.20
1/8 BSP Stainless solenoid valve model 21233.
Function: 2/2 way normally closed
Operation: direct acting
Port: 1/8 BSPP
Body: 303 stainless steel
Internals: stainless steel
Pressure: 0 to 100 Bar according to coil power and voltage
Flow: 0.7 L/Min according to orifice, based on water with 1 Bar pressure drop.
Temperature: -10 to +100°C Max
Media: air, water, light oils, vacuum and most other fluids under 50CST and gases compatible with materials of construction.
Coil: 11630 10 Watt IP65 CE approved Class F 100% duty rated DIN43650A
Coil: 31400 14-20 Watt IP65 CE approved Class F 100% duty rated DIN43650A
Protection: IP65 with connector (Included)
Voltage: 12vDC, 24vDC, 48vDC or 24vAC, 48vAC, 110vAC or 230vAC.
