Parker 705207M10M

Also known as MAXAM PE Heavy Duty In-line Valve is also a Parker 705207M10Mr discontinued 5/2 way valve but is available from Solenoid Valve World. Simply contact us.

Function: 5/2 way 5 port 2 position with spring return

Port: 1/4 or 1/2 Inch BSP or NPT thread

Sealing: NBR or FPM

Pressure: 2 to 10 Bar

Air Supply: Options with or without external air supply

Manual override options: Without, Plastic, Brass slot, Non locking stainless knob or locking stainless steel knob

Voltage options: 6 volt, 12 volts, 24 volts, 48 volts, 110 volts, 120 volts, 230 volts and 240 volts

Power options: AC 50 Hz 8 Watts, AC 60 Hz 8 Watts or DC 10 watts

Electrical connection option: Without, Standard DIN43650A, DIN43650A with LED, DIN43650A with LED and surge protection or Standard with 1/2 conduit entry.

The picture on the left is 1/4" BSP Brass 5/2 way spring return Pressure 1 to 10 Bar with external air pilot, NBR seal, Plastic Manual Override 24vDC 10 Watt coil with standard connector. PES-5-0-S-N-2-1-24-3-1.
