3/4 BSP Male plastic water solenoid valve 0.2-10 Bar normally closed single outlet 180 degree (S180)
£9.41
£17.51 incl. VATDescription
3/4 plastic washing machine water single solenoid valve WRAS approved S180
Function: 2/2 way normally closed
Operation: Pressure assisted (Min 0.2 Bar pressure differential)
Port: 3/4 BSP Male inlet with 180 degree (straight) single 104F 10.5mm or 120F 12.5mm hose tail outlet.
Pressure: 0.2 to 10 Bar
Orifice: 11.0mm
Body: Nylon white good grade GF
Coil: R 6.2 Watts IP00 with faston tag Class F 60% duty rated (Max 2 Min power ON with 3 min power OFF for cooling)
Voltage: 12vDC, 24vDC, 12vAC, 24vAC, 110vAC or 230vAC
Approvals: WRAS, KTW and DM174 for drinking water production, transfer and storage, ACS health compliance certificate, ENEC European Norms Electrical Certification, CSV (European Union Aviation Safety Agency), UL Underwriter Laboratories certified, MOCA FCM (Food Contact Materials), NSF food certification for public health protection.
This is the most common RPE type R cold water inlet Solenoid Valve for most domestic and commercial washing machine, dishwasher, drinking water dispensers and most other automated water control systems. Standard 3/4 BSP appliance hose fits directly onto the 3/4 BSP male thread.
Technical Specification
Brand: RPE srl
Model: S180
Width: 38.50 mm
Height: 61.00 mm
Depth: 61.50 mm
Weight: 0.15 kg
Valve / Product Type: Solenoid
Body Material: Nylon
Voltage: 110vAC, 12vAC, 12vDC, 230VAC, 24vAC, 24vDC
Port Size: 3/4 thread
Function: 2/2 Normally Closed
Operation: Pressure Assisted
Pressure Maximum: 2 Bar, 2.5 Bar, 3 Bar, 3.5 Bar, 4 Bar, 4.5 Bar, 5 Bar, 5.5 Bar, 6 Bar, 6.5 Bar, 7 Bar, 7.5 Bar, 8 Bar, 8.5 Bar, 9 Bar, 10 Bar
Seals: NBR
Approvals: IPX0 (Faston Tag), WRAS
Media: Water
Options required: Anti Water Hammer, Outlet - Hose tail, Mounting Bracket
Orifice: 11mm
