316 Stainless steel male stud push-in airline fitting M5 up to 1/2 BSP 4mm up to 12mm (S6PC)
£8.75
£17.51 incl. VATDescription
Stainless steel push in fitting: male straight S6PC
Seals: Viton
Body: 316 stainless steel
Thread: M5, 1/8, 1/4, 3/8 or 1/2 BSPT thread, option NPT thread
Speed fit sizes: 4mm, 6mm, 8mm, 10mm and 12mm
Pressure: 10 Bar maximum.
Temperature: 0 to +180°C
Tube: Polyurethane or Nylon
Technical Specification
Brand: Shako Co Ltd
Model: S6PC
Width: 10.00 mm
Height: 5.00 mm
Depth: 3.00 mm
Weight: 0.10 kg
Valve / Product Type: AirLine Fittings + Tube
Body Material: Stainless Steel
Port Size: 4mm, M5, 1/8 thread, 1/4 thread, 6mm, 8mm, 3/8 thread, 10mm, 12mm, 1/2 thread
Pressure Maximum: 0.02 Bar (20 mBar), 0.1 Bar (100 mBar), 0.2 Bar (200 mBar), 0.3 Bar (300 mBar), 0.4 Bar (400 mBar), 0.5 Bar (500 mBar), 0.6 Bar (600 mbar), 0.7 Bar (700 mBar), 0.8 Bar (800 mBar), 1 Bar, 1.2 Bar, 1.3 Bar, 1.4 Bar, 1.5 Bar, 1.6 Bar, 2 Bar, 2.5 Bar, 3 Bar, 3.5 Bar, 4 Bar, 4.5 Bar, 5 Bar, 5.5 Bar, 6 Bar, 6.5 Bar, 7 Bar, 7.5 Bar, 8 Bar, 8.5 Bar, 9 Bar, 10 Bar
Seals: FKM (Viton)
Media: Air, Fluid (Non Aggressive), Gases (Non Aggressive), Vacuum (Low), Water
